Horizon H-200 PEM fuel cell (FCS-C200)
|
|
|
PLANB_FULLICONS-ONE
PLANB_FULLICONS-TWO
PLANB_FULLICONS-THREE
PLANB_FULLICONS-FOUR
PLANB_FULLICONS-FIVE
? Ask a question
Description
The Horizon H-200 PEM Fuel Cell is a 200 Watt, air fed / air cooled, self-humidified hydrogen fuel cell. Because this fuel cell is air cooled there is no need for large, complicated, and expensive water cooling systems.
Horizon H-Series PEM fuel cells are semi-integrated, efficient, reliable systems that minimize the use of peripherals. As such, they are the most compact and lightweight fuel cells around the world.
Includes:
- Connections/Tubing
- Electronic valves
- Electronic control box
- 5kW stack with blower
- Fuel cell ON/OFF switch
- SCU ON/OFF switch
Fuel Cell Properties:
- Number of Cells: 40
- Rated Power: 200W
- Rated Performance: 24V @ 8.3 A
- Hydrogen Supply Valve Voltage: 12V
- Purging Valve Voltage: 12V
- Blower Voltage: 12 V
- Reactants: Hydrogen and Air
- Ambient Temperature: 5 - 30C (41 - 86F)
- Max Stack Temperature: 65 C (149 F)
- Hydrogen Pressure: 0.45 - 0.55 Bar
- Humidification: Self-humidified
- Cooling: Air (integrated cooling fan)
- Controller Weight: 400g (± 30g)
- Stack Weight (with Fan & Casing): 2230 (± 50)g
- Hydrogen Flow Rate at Max Output: 3.9 L/min
- Stack Size: 118 x 262 x 94mm (4.6" x 10.3" x 3.7")
- Hydrogen Purity Requirement: ≥ 99.995% (dry H2)
- Start up time: ≤ 30s (ambient temperature)
- Efficiency of System: 40% at 12V
- Low Voltage Protection: 20V
- Over Current Protection: 12A
- Over Temperature Protection: 65 C
- External Power Supply: 13V (±1V), 5A
Specifications-of-Horizon-fuel-cells-H-Series-Ing.pdf
