Sequential Logic Card (320-42)

+
-
Add to cart! Go to cart Remove from cart
Price on request

PLANB_FULLICONS-ONE

PLANB_FULLICONS-TWO

PLANB_FULLICONS-THREE

PLANB_FULLICONS-FOUR

PLANB_FULLICONS-FIVE

? Ask a question

Description

This practical resource introduces students to sequential logic through a range of practical activities. The card is designed for use with the Electronics Study Trainer (320-00).

Practical activities based around this card are provided on the digital curriculum disk provided with the trainer.

The card may also be used with our optional cloud-based software. This contains theory presentations, investigations, and assessments, which link directly to the practical activities carried out using this resource.

The Card Includes the Following:

  • D-type flip-flops (x3) with LED indicators
  • J-K flip-flops (x3) with LED indicators
  • 2-input NAND gates (x2) with LED indicators
  • 2-input AND gates (x2)
  • Switched faults for fault-finding activities

Practical tasks include the following:

  • Investigating a D-type flip-flop.
  • Investigating a J-K flip-flop.
  • Binary counter operation.
  • Frequency division.
  • Shift register operation.
  • Ring counter operation.
  • Testing and fault-finding sequential logic systems.

Items Included:

  • Circuit Card

Other Items Required:

General Information:

  • Card Dimensions: 160 x 100 x 20 mm (WхHхD)
  • Card Volume: 0.001 m3
  • Card Weight: 0.2 kg
