Rope Testing Machine

Description

Rope Testing Machine (Rope Testing Machine) is designed for tensile testing of steel ropes, chains, special tools and textile lines. The testing of products occurs by stretching to a certain amount of force created by the high pressure pumping station.

The stand is equipped with a double-acting hydraulic cylinder controlled by the pumping station, it is supplied with a hand pump, which can be replaced by a more efficient pump station with an electric drive.

The stand is completed:

• set of adapters of textile lines with a width
• unit for testing textile sling up to 16 meters
• adapters for steel ropes under the entire range of the scales
• block for testing of chain slings up to 16 meters long

Key features of the stand:

• The screw system of preliminary pulling of a sling, providing minimization of a working course of the hydraulic cylinder.
• It consists of several interconnected sections, which facilitates their transportation and installation in the workplace.
• The load is monitored by means of a manometer and a load cell located between the boom support and the rod of the hydraulic cylinder.
• By agreement, the stand can be equipped with a system for registering and automatically issuing a report with preservation in the database.

Main characteristics of the stand:

• Traction effort: from 10, 50, 100, 150, 200 tons;
• Diameter of cable ropes tested: up to 64 mm;
• Length of tested slings: Without additional tools -8 m. With additional attachments - 16 m;
• Stroke of the hydraulic cylinder: 400, 800, 1500 mm;
• Overall dimensions (LxWxH): 11x1,2x1 m;
• Ambient temperature range: -10 to + 40 ° C;
• Pump station: electric;
• Traction control: on the gauge gauge in kg / cm2;
• Preliminary mechanical pulling of the sling before testing;
• The frame is a team of bolted connections, consists of sections, a length of 2.5 m.
